Knowla Box
A multimedia, interactive device that is the heart of Knowla’s educational entertainment. Equipped with Epson’s top-quality short-focus projector, it can project a bright, large-format image horizontally and vertically. It provides a variety of ways to interact with the projected image: hitting balls, writing with pens, keyboard and mouse operation – soon also motion control and augmented reality (apps in development).
Knowla Box is designed to support the Knowla application packages, the so called Educational Planets, but it can also serve as a standalone center for multimedia entertainment.
Included with the device is an application starter pack: Planet Fruu with 120 educational and developmental activities for pre-school and early-school children (I-III).
The content of the package
01
Knowla Box: an integrated multimedia platform with a built-in computer with WiFi, Epson EB-760Wi projector, interactive screen, sensors and speakers. Fully assembled device ready to start.
02
starting planet Fruu with 250 activities and EduMini with 95 activities
03
40 balls
04
2 Epson Interactive Pens with Spare Tips
05
Epson remote
06
wireless keyboard with touchpad
07
basket for the balls
08
power cable
09
a bag for accessories
It supports development in every dimension.
As long as it is flat.
Bright image
The projector image is projected from the side, there are no shadows, dazzling light or blind spots, and the 4000 lumen high brightness laser light source also works when the lighting in the room is bright - there is no need to darken rooms. It is possible to watch from any angle.
Vertical and horizontal
Images can be displayed on any vertical or horizontal planes: walls, floor, benches. Interaction with the image takes place in both settings in the same way.
Interactions
Democratic
Multitasking
Innovative
Mobile
Easy-to-use
Intuitive to use, fast to run. It has an easy-to-use interface. Setup is quick and hassle-free.
Ready to go
Ready to use immediately after turning on, without the need for mounting and installations. Access to maintenance services, technical support and simple user manuals.
Model
Epson EB-760Wi
Projector type
laser, ultra short-focus – high-quality image displayed from a short distance
Technology
3LCD
Resolution
1280 x 800 WXGA
Contrast
2 500 000:1
Brightness
2.800 – 4.100 ANSI lm
Display
display on any flat surfaces horizontally and vertically
Image quality
projector image displayed from the side, without shadows, blinding light or blind spots, visible even in bright rooms
Size of the displayed image
Directly against the wall: width. 182 cm / H. 113 cm 15 cm from the wall: width. 227 cm / H. 142 cm On the floor: wide. 182 cm / H. 113 cm
Height
36,8 cm
Width
39,7 cm
Depth
58,3 cm
Weight
30 kg
Operating system
Windows 10
Technologies used
laser light source, ultrasound (unique impact-response sensors), Epson interactive pens
Types of interaction
1) hitting (ball), 2) writing / drawing (interactive pen)
Number of users
any (singly, in pairs, in groups)
Language of the menu
Polish, English, German, Ukrainian, Estonian, Spanish, French, Italian, Latvian, Lithuanian, Hungarian, Dutch, Russian, Romanian, Slovak, Czech, Greek
Built-in Speaker
35W 4Ω
Communication
1xHDMI 2.1, 1xUSB A
Standard WiFi
Wi-Fi 5 (802.11a/b/g/n/ac)
Power socket
IEC C13 (230V)
Tech
specifications
